SHARDA Hydraulic Cylindrical Grinding
SHARDA Hydraulic Universl Cylindrical Grindign Machine
Product Description
Machine Base
The machine base is manufactured of one piece close grained graded cast Iron box type design, heavily reinforced with ribs provide high rigidity & stability.
Machine Guideways
V & Flat guide ways precisely hand scrapped with continuous automatic lubrication.
Grinding Wheel Slide is coated with Turcite coated which gives stick slip free movement, excellent vibration damping and high positioning accuracy.
Work Head
The machine has a rigid Universal Work Head, which can be swivelled to facilitate taper grinding.
The drive to the work head is built for stationery and live spindle grinding.
Work Head with Antifriction bearings and variable frequency drive offered as optional.
Wheel Head
Wheel Head Spindle is made of special alloy steel ground and micro finish to achieve high dimensional stability and long life.
Spindles runs in precision white metal bearings which give high accuracy and excellent surface finish to the work piece.
Cartridge type grinding wheel head spindle with precision antifriction can be offered as optional.
Tail Stock
Rigid Tail stock
Tail stock is spring loaded and can accept MT-3 Taper
Hydraulic Actuation & Micro Taper correction facility in optional.
Internal Grinding Attachment (Optional)
This unit with its independent drive motor is hinged on the wheel head and can be quickly lowered in to grinding position
The drive to the spindle is transmitted by flat belt.
Coolant
Coolant supply is provided with electrical pump fitted on separate tank
Electricals
The machine is supplied with all electrical suitable for 440V, AC, 50 Hzs. The motors are of reputed make, The electrical panel is mounted on one side of the machine, Push button station is located at easy reach of the operator.
Note
- Technical Specification
| Capacity | U-127-300 | U-127-500 | U-127-625 | U-127-750 | U-127-1000 | U-127-1250 | U-127-1500 | U-127-2000 |
|---|---|---|---|---|---|---|---|---|
| Swing over Table | 254 mm / 300 mm / 350 mm | 254 mm / 300 mm / 350 mm | 254 mm / 300 mm / 350 mm | 254 mm / 300 mm / 350 mm | 254 mm / 300 mm / 350 mm | 254 mm / 300 mm / 350 mm | 254 mm / 300 mm / 350 mm | 254 mm / 300 mm / 350 mm |
| Admit Between Centres | 300 mm | 500 mm | 625 mm | 750 mm | 1000 mm | 1250 mm | 1500 mm | 2000 mm |
| Maximum Swivel Of Table | 7+2=9 deg | 6+2=8 deg | 6+2=9 deg | 6+2=8 deg | 6+2=8 deg | 5+2=7 deg | 5+2=7 deg | 4+2=6 deg |
| Table Speed Min - Max | 400 mm/min - 5000 mm/min | 400 mm/min - 5000 mm/min | 400 mm/min - 5000 mm/min | 400 mm/min - 5000 mm/min | 400 mm/min - 5000 mm/min | 400 mm/min - 5000 mm/min | 400 mm/min - 5000 mm/min | 400 mm/min - 5000 mm/min |
| Grinding Wheel Diameter | 350 mm / 400 mm | 350 mm / 400 mm | 350 mm / 400 mm | 350 mm / 400 mm | 350 mm / 400 mm | 350 mm / 400 mm | 350 mm / 400 mm | 350 mm / 400 mm |
| Grinding Wheel Width | 40 mm / 50 mm | 40 mm / 50 mm | 40 mm / 50 mm | 40 mm / 50 mm | 40 mm / 50 mm | 40 mm / 50 mm | 40 mm / 50 mm | 40 mm / 50 mm |
| Wheel Head Rapid Approach | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm |
| Speed of Grinding Wheel | 1600 rpm - 2090 rpm | 1600 rpm - 2090 rpm | 1600 rpm - 2090 rpm | 1600 rpm - 2090 rpm | 1600 rpm - 2090 rpm | 1600 rpm - 2090 rpm | 1600 rpm - 2090 rpm | 1600 rpm - 2090 rpm |
| Speed of Work Head | 60 rpm – 120 rpm – 212 rpm -380 rpm / Variable Frequency Drive | 60 rpm – 120 rpm – 212 rpm -380 rpm / Variable Frequency Drive | 60 rpm – 120 rpm – 212 rpm -380 rpm / Variable Frequency Drive | 60 rpm – 120 rpm – 212 rpm -380 rpm / Variable Frequency Drive | 60 rpm – 120 rpm – 212 rpm -380 rpm / Variable Frequency Drive | 60 rpm – 120 rpm – 212 rpm -380 rpm / Variable Frequency Drive | 60 rpm – 120 rpm – 212 rpm -380 rpm / Variable Frequency Drive | 60 rpm – 120 rpm – 212 rpm -380 rpm / Variable Frequency Drive |
| Swivel of Work Head | 0 - 90 deg | 0 - 90 deg | 0 - 90 deg | 0 - 90 deg | 0 - 90 deg | 0 - 90 deg | 0 - 90 deg | 0 - 90 deg |
| Work Head Spindle Nose Taper | MT 4 | MT 4 | MT 4 | MT 4 | MT 4 | MT 4 | MT 4 | MT 4 |
| Tail Stock Spindle Nose Taper | MT 3 | MT 3 | MT 3 | MT 3 | MT 3 | MT 3 | MT 3 | MT 3 |
| Internal Grinding Spindle Dia. | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm |
| Weight Approx. | 1800Kg | 2000 kg | 2100 kg | 2500 kg | 3000 kg | 3100 kg | 3300 kg | 3800 kg |
| Floor Space (L x W) | 2400 mm X 1260 mm | 2760 mm X 1260 mm | 2950 mm X 1260 mm | 3410 mm X 1260 mm | 4370 mm X 1260 mm | 4870 mm X 1260 mm | 5760 mm X 1260 mm | 6760 mm X 1260 mm |
